Training a Model on Multiple GPUs with Data Parallelism

Source: MachineLearningMastery.com

Training a large language model is slow. If you have multiple GPUs, you can accelerate training by distributing the workload across them to run in parallel. In this article, you will learn about data parallelism techniques. In particular, you will learn about:

What is data parallelism
The difference between Data Parallel and Distributed Data Parallel in PyTorch
How to train a model with data parallelism

Let’s get started!

Training a Model on Multiple GPUs with Data Parallelism
Photo by Ilse Orsel. Some rights reserved.

Overview

This article is divided into two parts; they are:

Data Parallelism
Distributed Data Parallelism

Data Parallelism

If you have multiple GPUs, you can combine them to operate as a single GPU with greater memory capacity. This technique is called data parallelism. Essentially, you copy the model to each GPU, but each processes a different subset of the data. Then you aggregate the results for the gradient update.

Data parallelism is to share the same model with multiple processors to work on different data.

This is not focused on speed. In fact, switching to data parallelism may slow down training due to extra communication overhead.

Data parallelism is useful when a model still fits on a single GPU but cannot be trained with a large batch size due to memory constraints. In this case, you can use gradient accumulation. This is equivalent to running small batches on multiple GPUs and then aggregating the gradients, as in data parallelism.

Running a PyTorch model with data parallelism is easy. All you need to do is wrap the model with nn.DataParallel. The result is a new model that can distribute and aggregate data across all local GPUs.

Consider the training loop from the previous article, you just need to wrap the model right after you create it:

...

model_config = LlamaConfig()

model = LlamaForPretraining(model_config)

if torch.cuda.device_count() > 1:

print(f“Using {torch.cuda.device_count()} GPUs”)

model = nn.DataParallel(model) # wrap the model for DataParallel

model.train()

...

# start training

for epoch in range(epochs):

pbar = tqdm.tqdm(dataloader, desc=f“Epoch {epoch+1}/{epochs}”)

for batch_id, batch in enumerate(pbar):

# get batched data

input_ids, target_ids = batch

# create attention mask: causal mask + padding mask

attn_mask = create_causal_mask(input_ids.shape[1], device) +

create_padding_mask(input_ids, PAD_TOKEN_ID, device)

# extract output from model

logits = model(input_ids, attn_mask)

# compute loss: cross-entropy between logits and target, ignoring padding tokens

loss = loss_fn(logits.view(–1, logits.size(–1)), target_ids.view(–1))

# backward with loss and gradient clipping

optimizer.zero_grad()

loss.backward()

torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)

optimizer.step()

scheduler.step()

pbar.set_postfix(loss=loss.item())

pbar.update(1)

pbar.close()

torch.save(

model.module.state_dict() if isinstance(model, nn.DataParallel) else model.state_dict(),

“model.pth”

)

You can see that nothing has changed in the training loop. But when you created the model, you wrapped it with nn.DataParallel. The wrapped model is a proxy for the original model but distributes data across multiple GPUs. Every GPU has an identical copy of the model. When you run the model with a batched tensor, the tensor is split across GPUs, and each GPU processes a micro-batch. The results are then aggregated to produce the output tensor.

Similarly, for the backward pass, each GPU computes the gradient for its micro-batch, and the final gradient is aggregated across all GPUs to update the model parameters.

From the user’s perspective, a model trained in data parallelism is no different from a single-GPU model. However, when you save the model, you should save the underlying model, accessible as model.module. When loading the model, load the original model first, then wrap it with nn.DataParallel again.

Note that when you run the training loop as above, the first GPU will consume most of the memory because it holds the master copy of the model parameters and gradients, as well as the optimizer and scheduler state. If you require precise control, you can specify the list of GPUs to use and the device on which to store the master copy of the model parameters.

if torch.cuda.device_count() > 1:

print(f“Using {torch.cuda.device_count()} GPUs”)

model = nn.DataParallel(model, device_ids=[0, 1, 2, 3], output_device=0)

Distributed Data Parallel

PyTorch DataParallel runs as a multithreaded program. This can be problematic because Python multithreading performance is limited.

Therefore, PyTorch recommends using Distributed Data Parallel (DDP) instead, even when running on a single machine with multiple GPUs. DDP uses a multi-process model in which each GPU runs as a separate process, thereby avoiding the performance bottleneck of multithreading.

Using Distributed Data Parallel is more complex. First, you need to use the torchrun command to launch the program instead of the python command so that the communication infrastructure is set up correctly. Second, your code needs to be modified: A process group needs to be created, your model needs to be wrapped, and the DataLoader needs a sampler to distribute the data across processes. Finally, because there are multiple processes, model checkpointing should be performed only in the master process.

Consider the training script from the previous article, you need to modify several parts:

Before you create the model, you should initialize the process group. Distributed Data Parallel is a PyTorch distributed framework. The total number of workers is called the world size. Each worker has a unique rank, typically starting at 0 and increasing up to the world size minus 1. A worker should map to a distinct GPU device. Because workers may span multiple machines, the GPU device ID on each machine does not correspond to the rank. Therefore, local rank is used to identify the GPU device on the current machine.

To initialize the process group, you need to add a few lines of code before you create the model:

...

import torch.distributed as dist

from torch.nn.parallel import DistributedDataParallel as DDP

# Initialize the distributed environment

dist.init_process_group(backend=“nccl”)

rank = dist.get_rank()

local_rank = int(os.environ[“LOCAL_RANK”])

world_size = dist.get_world_size()

device = torch.device(f“cuda:{local_rank}”)

print(f“World size: {world_size}, Rank: {rank}, Local rank: {local_rank}. Using device: {device}”)

# Create pretraining model with default config, then wrap it in DDP

model_config = LlamaConfig()

model = LlamaForPretraining(model_config).to(rank)

model = DDP(model, device_ids=[local_rank]) # , output_device=local_rank)

model.train()

The rank, local_rank, and world_size are integers that you will need later. You can obtain these values only after you call init_process_group(), and they differ for each process launched. You do not need GPUs to run distributed data parallel since PyTorch also supports CPU backends (called gloo). However, you should see reasonable performance for LLM training only on GPUs. For Nvidia GPUs, the NCCL backend (Nvidia Collective Communication Library) should be used.

Note that you must not set the default device explicitly using torch.set_default_device(). This is the job of DDP, and you must not interfere with it.

When you create a model, you should send it to the specific rank you are on, then wrap it with DDP. The wrapped model is the model you should use, so that communication between processes occurs behind the scenes.

In DDP, the same model is replicated across multiple GPUs, and each GPU processes a different subset of the data. You need to make sure your process sees the correct subset:

...

from torch.utils.data.distributed import DistributedSampler

# Generator function to create padded sequences of fixed length

class PretrainingDataset(torch.utils.data.Dataset):

def __init__(self, dataset: datasets.Dataset, tokenizer: tokenizers.Tokenizer, seq_length: int):

self.dataset = dataset

self.tokenizer = tokenizer

self.seq_length = seq_length

self.bot = tokenizer.token_to_id(“[BOT]”)

self.eot = tokenizer.token_to_id(“[EOT]”)

self.pad = tokenizer.token_to_id(“[PAD]”)

def __len__(self):

return len(self.dataset)

def __getitem__(self, index):

“”“Get a sequence of token ids from the dataset. [BOT] and [EOT] tokens

are added. Clipped and padded to the sequence length.

““”

seq = self.dataset[index][“text”]

tokens: list[int] = [self.bot] + self.tokenizer.encode(seq).ids + [self.eot]

# pad to target sequence length

toklen = len(tokens)

if toklen < self.seq_length+1:

pad_length = self.seq_length+1 – toklen

tokens += [self.pad] * pad_length

# return the sequence

x = torch.tensor(tokens[:self.seq_length], dtype=torch.int64)

y = torch.tensor(tokens[1:self.seq_length+1], dtype=torch.int64)

return x, y

batch_size = 64 // world_size

dataset = PretrainingDataset(dataset, tokenizer, seq_length)

sampler = DistributedSampler(dataset, shuffle=False)

dataloader = torch.utils.data.DataLoader(

dataset,

batch_size=batch_size,

sampler=sampler,

pin_memory=True, # optional

shuffle=False,

num_workers=world_size,

)

In the previous article, the customized Dataset class draws a text sample from the dataset and converts it into two tokenized tensors: one for the input and one for the target. They were created directly on the target device. In DDP, you need to create them in CPU memory and let DDP send them to the appropriate device. Hence, you modified the PretrainingDataset class to remove device management.

The subset of training data is selected by the DistributedSampler. It will determine the rank of the current process to ensure that the data is partitioned correctly. To use the sampler, you should specify it in the DataLoader as shown above. Also note that, in our design, no data shuffling is required. Hence, shuffle=False is specified in both the DistributedSampler and the DataLoader. However, if you need to shuffle the data, you should specify shuffle=True in the DistributedSampler only and leave shuffle=False in the DataLoader. You also need to set sampler.set_epoch(epoch) at the beginning of each epoch to trigger a new shuffle.

The pin_memory=True argument in DataLoader is optional. It uses a pinned memory buffer to store data, which is faster for moving data from the CPU to the GPU.

DDP differs from DataParallel in that you are responsible for creating the micro-batches for training. This means that the batch_size argument in DataLoader refers to the micro-batch size used in the process, not the effective batch size per training step. Since you have world_size number of processes, you should divide the effective batch size by world_size to get the micro-batch size.

During training, most of the code is the same as before, except you want to leave the checkpointing to the process with rank 0 only:

...

for epoch in range(epochs):

pbar = tqdm.tqdm(dataloader, desc=f“Epoch {epoch+1}/{epochs}”)

sampler.set_epoch(epoch) # required for shuffling only

for batch_id, batch in enumerate(pbar):

if batch_id % 1000 == 0 and rank == 0:

# checkpoint the model and optimizer state, only on rank 0 process

torch.save({

“model”: model.module.state_dict() if isinstance(model, DDP) else model.state_dict(),

“optimizer”: optimizer.state_dict(),

“scheduler”: scheduler.state_dict(),

“epoch”: epoch,

“batch”: batch_id,

}, f“llama_pretraining_checkpoint.pth”)

# get batched data, move from CPU to GPU

input_ids, target_ids = batch

input_ids = input_ids.to(device)

target_ids = target_ids.to(device)

# create attention mask: causal mask + padding mask

attn_mask = create_causal_mask(input_ids) +

create_padding_mask(input_ids, PAD_TOKEN_ID)

# extract output from model

logits = model(input_ids, attn_mask)

# compute loss: cross-entropy between logits and target, ignoring padding tokens

loss = loss_fn(logits.view(–1, logits.size(–1)), target_ids.view(–1))

# backward with loss and gradient clipping

optimizer.zero_grad()

loss.backward()

torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)

optimizer.step()

scheduler.step()

pbar.set_postfix(loss=loss.item())

pbar.update(1)

pbar.close()

# Save the model

if rank == 0:

torch.save(model.state_dict(), “llama_pretraining_model.pth”)

torch.save(model.base_model.state_dict(), “llama_model.pth”)

# Clean up the distributed environment

dist.destroy_process_group()

The batch is created in CPU memory and will be moved to the appropriate device once it is passed to the model. However, when computing the loss, the loss function requires that the output tensor logits and the target tensor target_ids be on the same device. Therefore, it is preferable to transfer them to the appropriate device in the first place.

You can see that invoking the model for the forward pass or applying the backward pass is identical to before. However, when you run torch.save() to save the model, you do that only when rank == 0. This avoids multiple processes writing to the same file simultaneously.

Finally, at the end of the program, you should destroy the process group to clean up the distributed environment.

When you finish the script, you can run it with the following command on a single computer with multiple GPUs:

torchrun —standalone —nproc_per_node=4 training_ddp.py

The nproc_per_node argument specifies the number of GPUs to use. You can also use the CUDA_VISIBLE_DEVICES environment variable to specify which GPUs to use. If you need to run it on multiple machines, you should run this command:

torchrun —nnodes=2 —nproc_per_node=4 —node_rank=0 —master_addr=10.1.1.1 —master_port=12345 training_ddp.py

where --master_addr and --master_port are the address and port of the **master node**. The address should be the IP address of the master node where the server should be brought up. On the master node, --node_rank must be 0. On other nodes, --node_rank counts from 1 onwards and should be consistent with the --nnodes (total number of nodes) argument. All nodes should have the same command-line arguments, except for --node_rank, so they run the same program and communicate with the same server.

The complete code for DDP training is as follows:

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

import dataclasses

import os

import datasets

import tqdm

import tokenizers

import torch

import torch.distributed as dist

import torch.nn as nn

import torch.nn.functional as F

import torch.optim.lr_scheduler as lr_scheduler

from torch import Tensor

from torch.nn.parallel import DistributedDataParallel as DDP

from torch.utils.data.distributed import DistributedSampler

# Build the model

@dataclasses.dataclass

class LlamaConfig:

“”“Define Llama model hyperparameters.”“”

vocab_size: int = 50000 # Size of the tokenizer vocabulary

max_position_embeddings: int = 2048 # Maximum sequence length

hidden_size: int = 768 # Dimension of hidden layers

intermediate_size: int = 4*768 # Dimension of MLP’s hidden layer

num_hidden_layers: int = 12 # Number of transformer layers

num_attention_heads: int = 12 # Number of attention heads

num_key_value_heads: int = 3 # Number of key-value heads for GQA

class RotaryPositionEncoding(nn.Module):

“”“Rotary position encoding.”“”

def __init__(self, dim: int, max_position_embeddings: int) -> None:

“”“Initialize the RotaryPositionEncoding module

Args:

dim: The hidden dimension of the input tensor to which RoPE is applied

max_position_embeddings: The maximum sequence length of the input tensor

““”

super().__init__()

self.dim = dim

self.max_position_embeddings = max_position_embeddings

# compute a matrix of ntheta_i

N = 10_000.0

inv_freq = 1.0 / (N ** (torch.arange(0, dim, 2) / dim))

inv_freq = torch.cat((inv_freq, inv_freq), dim=–1)

position = torch.arange(max_position_embeddings)

sinusoid_inp = torch.outer(position, inv_freq)

# save cosine and sine matrices as buffers, not parameters

self.register_buffer(“cos”, sinusoid_inp.cos())

self.register_buffer(“sin”, sinusoid_inp.sin())

def forward(self, x: Tensor) -> Tensor:

“”“Apply RoPE to tensor x

Args:

x: Input tensor of shape (batch_size, seq_length, num_heads, head_dim)

Returns:

Output tensor of shape (batch_size, seq_length, num_heads, head_dim)

““”

batch_size, seq_len, num_heads, head_dim = x.shape

dtype = x.dtype

# transform the cosine and sine matrices to 4D tensor and the same dtype as x

cos = self.cos.to(dtype)[:seq_len].view(1, seq_len, 1, –1)

sin = self.sin.to(dtype)[:seq_len].view(1, seq_len, 1, –1)

# apply RoPE to x

x1, x2 = x.chunk(2, dim=–1)

rotated = torch.cat((–x2, x1), dim=–1)

output = (x * cos) + (rotated * sin)

return output

class LlamaAttention(nn.Module):

“”“Grouped-query attention with rotary embeddings.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.hidden_size = config.hidden_size

self.num_heads = config.num_attention_heads

self.head_dim = self.hidden_size // self.num_heads

self.num_kv_heads = config.num_key_value_heads # GQA: H_kv < H_q

# hidden_size must be divisible by num_heads

assert (self.head_dim * self.num_heads) == self.hidden_size

# Linear layers for Q, K, V projections

self.q_proj = nn.Linear(self.hidden_size, self.num_heads * self.head_dim, bias=False)

self.k_proj = nn.Linear(self.hidden_size, self.num_kv_heads * self.head_dim, bias=False)

self.v_proj = nn.Linear(self.hidden_size, self.num_kv_heads * self.head_dim, bias=False)

self.o_proj = nn.Linear(self.num_heads * self.head_dim, self.hidden_size, bias=False)

def forward(self, hidden_states: Tensor, rope: RotaryPositionEncoding, attn_mask: Tensor) -> Tensor:

bs, seq_len, dim = hidden_states.size()

# Project inputs to Q, K, V

query_states = self.q_proj(hidden_states).view(bs, seq_len, self.num_heads, self.head_dim)

key_states = self.k_proj(hidden_states).view(bs, seq_len, self.num_kv_heads, self.head_dim)

value_states = self.v_proj(hidden_states).view(bs, seq_len, self.num_kv_heads, self.head_dim)

# Apply rotary position embeddings

query_states = rope(query_states)

key_states = rope(key_states)

# Transpose tensors from BSHD to BHSD dimension for scaled_dot_product_attention

query_states = query_states.transpose(1, 2)

key_states = key_states.transpose(1, 2)

value_states = value_states.transpose(1, 2)

# Use PyTorch’s optimized attention implementation

# setting is_causal=True is incompatible with setting explicit attention mask

attn_output = F.scaled_dot_product_attention(

query_states,

key_states,

value_states,

attn_mask=attn_mask,

dropout_p=0.0,

enable_gqa=True,

)

# Transpose output tensor from BHSD to BSHD dimension, reshape to 3D, and then project output

attn_output = attn_output.transpose(1, 2).reshape(bs, seq_len, self.hidden_size)

attn_output = self.o_proj(attn_output)

return attn_output

class LlamaMLP(nn.Module):

“”“Feed-forward network with SwiGLU activation.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

# Two parallel projections for SwiGLU

self.gate_proj = nn.Linear(config.hidden_size, config.intermediate_size, bias=False)

self.up_proj = nn.Linear(config.hidden_size, config.intermediate_size, bias=False)

self.act_fn = F.silu # SwiGLU activation function

# Project back to hidden size

self.down_proj = nn.Linear(config.intermediate_size, config.hidden_size, bias=False)

def forward(self, x: Tensor) -> Tensor:

# SwiGLU activation: multiply gate and up-projected inputs

gate = self.act_fn(self.gate_proj(x))

up = self.up_proj(x)

return self.down_proj(gate * up)

class LlamaDecoderLayer(nn.Module):

“”“Single transformer layer for a Llama model.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.input_layernorm = nn.RMSNorm(config.hidden_size, eps=1e–5)

self.self_attn = LlamaAttention(config)

self.post_attention_layernorm = nn.RMSNorm(config.hidden_size, eps=1e–5)

self.mlp = LlamaMLP(config)

def forward(self, hidden_states: Tensor, rope: RotaryPositionEncoding, attn_mask: Tensor) -> Tensor:

# First residual block: Self-attention

residual = hidden_states

hidden_states = self.input_layernorm(hidden_states)

attn_outputs = self.self_attn(hidden_states, rope=rope, attn_mask=attn_mask)

hidden_states = attn_outputs + residual

# Second residual block: MLP

residual = hidden_states

hidden_states = self.post_attention_layernorm(hidden_states)

hidden_states = self.mlp(hidden_states) + residual

return hidden_states

class LlamaModel(nn.Module):

“”“The full Llama model without any pretraining heads.”“”

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.rotary_emb = RotaryPositionEncoding(

config.hidden_size // config.num_attention_heads,

config.max_position_embeddings,

)

self.embed_tokens = nn.Embedding(config.vocab_size, config.hidden_size)

self.layers = nn.ModuleList([LlamaDecoderLayer(config) for _ in range(config.num_hidden_layers)])

self.norm = nn.RMSNorm(config.hidden_size, eps=1e–5)

def forward(self, input_ids: Tensor, attn_mask: Tensor) -> Tensor:

# Convert input token IDs to embeddings

hidden_states = self.embed_tokens(input_ids)

# Process through all transformer layers, then the final norm layer

for layer in self.layers:

hidden_states = layer(hidden_states, rope=self.rotary_emb, attn_mask=attn_mask)

hidden_states = self.norm(hidden_states)

# Return the final hidden states

return hidden_states

class LlamaForPretraining(nn.Module):

def __init__(self, config: LlamaConfig) -> None:

super().__init__()

self.base_model = LlamaModel(config)

self.lm_head = nn.Linear(config.hidden_size, config.vocab_size, bias=False)

def forward(self, input_ids: Tensor, attn_mask: Tensor) -> Tensor:

hidden_states = self.base_model(input_ids, attn_mask)

return self.lm_head(hidden_states)

def create_causal_mask(batch: Tensor, dtype: torch.dtype = torch.float32) -> Tensor:

“”“Create a causal mask for self-attention.

Args:

batch: Batch of sequences, shape (batch_size, seq_len)

dtype: Data type of the mask

Returns:

Causal mask of shape (seq_len, seq_len)

““”

batch_size, seq_len = batch.shape

mask = torch.full((seq_len, seq_len), float(‘-inf’), device=batch.device, dtype=dtype)

.triu(diagonal=1)

return mask

def create_padding_mask(batch: Tensor, padding_token_id: int, dtype: torch.dtype = torch.float32) -> Tensor:

“”“Create a padding mask for a batch of sequences for self-attention.

Args:

batch: Batch of sequences, shape (batch_size, seq_len)

padding_token_id: ID of the padding token

dtype: Data type of the mask

Returns:

Padding mask of shape (batch_size, 1, seq_len, seq_len)

““”

padded = torch.zeros_like(batch, device=batch.device, dtype=dtype)

.masked_fill(batch == padding_token_id, float(‘-inf’))

mask = padded[:,:,None] + padded[:,None,:]

return mask[:, None, :, :]

# Generator function to create padded sequences of fixed length

class PretrainingDataset(torch.utils.data.Dataset):

def __init__(self, dataset: datasets.Dataset, tokenizer: tokenizers.Tokenizer,

seq_length: int):

self.dataset = dataset

self.tokenizer = tokenizer

self.seq_length = seq_length

self.bot = tokenizer.token_to_id(“[BOT]”)

self.eot = tokenizer.token_to_id(“[EOT]”)

self.pad = tokenizer.token_to_id(“[PAD]”)

def __len__(self):

return len(self.dataset)

def __getitem__(self, index):

“”“Get a sequence of token ids from the dataset. [BOT] and [EOT] tokens

are added. Clipped and padded to the sequence length.

““”

seq = self.dataset[index][“text”]

tokens: list[int] = [self.bot] + self.tokenizer.encode(seq).ids + [self.eot]

# pad to target sequence length

toklen = len(tokens)

if toklen < self.seq_length+1:

pad_length = self.seq_length+1 – toklen

tokens += [self.pad] * pad_length

# return the sequence

x = torch.tensor(tokens[:self.seq_length], dtype=torch.int64)

y = torch.tensor(tokens[1:self.seq_length+1], dtype=torch.int64)

return x, y

# Load the tokenizer

tokenizer = tokenizers.Tokenizer.from_file(“bpe_50K.json”)

# Load the dataset

dataset = datasets.load_dataset(“HuggingFaceFW/fineweb”, “sample-10BT”, split=“train”)

# Initialize the distributed environment

dist.init_process_group(backend=“nccl”)

rank = dist.get_rank()

local_rank = int(os.environ[“LOCAL_RANK”])

world_size = dist.get_world_size()

device = torch.device(f“cuda:{local_rank}”)

print(f“World size: {world_size}, Rank: {rank}, Local rank: {local_rank}. Using device: {device}”)

#torch.cuda.set_device(local_rank)

#torch.set_default_device(device)

# Create pretraining model with default config, then wrap it in DDP

model_config = LlamaConfig()

model = LlamaForPretraining(model_config).to(rank)

model = DDP(model, device_ids=[local_rank]) # , output_device=local_rank)

model.train()

# print the model size

print(f“Model parameters size: {sum(p.numel() for p in model.parameters()) / 1024**2:.2f} M”)

print(f“Model buffers size: {sum(p.numel() for p in model.buffers()) / 1024**2:.2f} M”)

print(f“Model precision(s): {set([x.dtype for x in model.state_dict().values()])}”)

# Training parameters

epochs = 3

learning_rate = 1e–3

batch_size = 64

seq_length = 512

num_warmup_steps = 1000

PAD_TOKEN_ID = tokenizer.token_to_id(“[PAD]”)

# DataLoader, optimizer, scheduler, and loss function

dataset = PretrainingDataset(dataset, tokenizer, seq_length)

sampler = DistributedSampler(dataset, shuffle=False)

dataloader = torch.utils.data.DataLoader(

dataset,

batch_size=batch_size,

sampler=sampler,

pin_memory=True, # optional

shuffle=False,

num_workers=world_size,

)

optimizer = torch.optim.AdamW(

model.parameters(), lr=learning_rate, betas=(0.9, 0.99), eps=1e–8, weight_decay=0.1

)

num_training_steps = len(dataloader) * epochs

print(f“Number of training steps: {num_training_steps} = {len(dataloader)} * {epochs}”)

warmup_scheduler = lr_scheduler.LinearLR(

optimizer,

start_factor=0.1, end_factor=1.0, total_iters=num_warmup_steps

)

cosine_scheduler = lr_scheduler.CosineAnnealingLR(

optimizer,

T_max=num_training_steps – num_warmup_steps,

eta_min=0

)

scheduler = lr_scheduler.SequentialLR(

optimizer,

schedulers=[warmup_scheduler, cosine_scheduler],

milestones=[num_warmup_steps]

)

loss_fn = nn.CrossEntropyLoss(ignore_index=PAD_TOKEN_ID)

# start training

for epoch in range(epochs):

pbar = tqdm.tqdm(dataloader, desc=f“Epoch {epoch+1}/{epochs}”)

sampler.set_epoch(epoch) # required for shuffling only

for batch_id, batch in enumerate(pbar):

if batch_id % 1000 == 0 and rank == 0:

# checkpoint the model and optimizer state, only on rank 0 process

torch.save({

“model”: model.module.state_dict() if isinstance(model, DDP) else model.state_dict(),

“optimizer”: optimizer.state_dict(),

“scheduler”: scheduler.state_dict(),

“epoch”: epoch,

“batch”: batch_id,

}, f“llama_pretraining_checkpoint.pth”)

# get batched data, move from CPU to GPU

input_ids, target_ids = batch

input_ids = input_ids.to(device)

target_ids = target_ids.to(device)

# create attention mask: causal mask + padding mask

attn_mask = create_causal_mask(input_ids) +

create_padding_mask(input_ids, PAD_TOKEN_ID)

# extract output from model

logits = model(input_ids, attn_mask)

# compute loss: cross-entropy between logits and target, ignoring padding tokens

loss = loss_fn(logits.view(–1, logits.size(–1)), target_ids.view(–1))

# backward with loss and gradient clipping by L2 norm to 1.0

optimizer.zero_grad()

loss.backward()

torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)

optimizer.step()

scheduler.step()

pbar.set_postfix(loss=loss.item())

pbar.update(1)

pbar.close()

# Save the model

if rank == 0:

torch.save(model.state_dict(), “llama_pretraining_model.pth”)

torch.save(model.base_model.state_dict(), “llama_model.pth”)

# Clean up the distributed environment

dist.destroy_process_group()

This code has been tested on a single machine with 4 data center-grade GPUs. You will find that with Data Parallel (single process, multi-threaded), the performance is 4 training steps per second. However, DDP can boost this to 18 training steps per second. Memory consumption in Data Parallel is unbalanced, with the first GPU consuming most of the memory as it serves as the master copy of the entire model. With DDP, all GPUs consume the same amount of memory, resulting in lower total memory consumption. Therefore, DDP is the recommended approach for training on multiple GPUs.

Summary

In this article, you have learned about Data Parallelism and Distributed Data Parallel. Data Parallelism is a technique for training a model across multiple GPUs. Distributed Data Parallel is a more advanced technique that enables training a model on a single or multiple machines. You will find that using nn.DataParallel is easier. Using DDP requires more code but offers greater power.

Training a Model on Multiple GPUs with Data Parallelism

Overview

Data Parallelism

Distributed Data Parallel

Further Readings

Summary

No comments yet.
