A Coding Implementation to Build Multi-Agent AI Systems with SmolAgents Using Code Execution, Tool Calling, and Dynamic Orchestration

import subprocess, sys   def pip(*args):    subprocess.check_call([sys.executable, "-m", "pip", "install", "-q", *args])   pip("smolagents[all]", "duckduckgo-search", "wikipedia", "rich")   import os, math, textwrap from rich.console import Console from rich.panel   import Panel from rich.table   import Table from rich         import print as rprint   console = Console()   def section(title: str, color: str = "bold cyan"):    console.rule(f"[{color}]{title}[/{color}]")   def show(label: str, value):    console.print(Panel(str(value), title=f"[bold yellow]{label}[/bold yellow]", expand=False))   import getpass   OPENAI_API_KEY = os.getenv("OPENAI_API_KEY") if not OPENAI_API_KEY:    OPENAI_API_KEY = getpass.getpass("🔑 Enter your OpenAI API key: ")    os.environ["OPENAI_API_KEY"] = OPENAI_API_KEY   console.print("[green]✓ OpenAI API key loaded.[/green]")   section("SECTION 1 · SmolAgents Architecture")   console.print(Panel(""" SmolAgents (HuggingFace) is a minimalist agent framework. Current stable release: 1.24.0   |   Using: OpenAI gpt-4o-mini   CORE ABSTRACTIONS  Tool  agent.tools (dict)  ToolCollection  LiteLLMModel  CodeAgent  ToolCallingAgent   MULTI-AGENT  (v1.8+ API)  Pass sub-agents directly via  managed_agents=[sub_agent]  Sub-agents need  name=  and  description=  set at init.  ManagedAgent wrapper class was removed in v1.8.0.   EXECUTION LOOP (CodeAgent)  Task ──► LLM writes Python ──► sandbox executes it       ◄── observation (tool output / exception) ◄──  Repeats up to max_steps, then calls final_answer(...) """, title="[bold green]Architecture[/bold green]"))

section("SECTION 2 · Building Custom Tools")   from smolagents import Tool, tool   @tool def celsius_to_fahrenheit(celsius: float) -> str:    return f"{celsius}°C = {celsius * 9/5 + 32:.2f}°F"   class PrimeTool(Tool):      name        = "prime_checker"    description = (        "If composite, returns the smallest prime factor."    )    inputs = {        "n": {"type": "integer", "description": "Positive integer to test."}    }    output_type = "string"      def forward(self, n: int) -> str:        if n < 2:            return f"{n} is not prime (must be >= 2)."        for i in range(2, int(math.isqrt(n)) + 1):            if n % i == 0:                return f"{n} is NOT prime. Smallest factor: {i}."        return f"{n} IS prime!"   class MemoTool(Tool):      name        = "memory_store"    description = (        "Stores or retrieves key-value pairs. "        "action='set' stores key+value; "        "action='get' retrieves by key; "        "action='list' shows all keys."    )    inputs = {        "action": {"type": "string", "description": "set | get | list"},        "key":    {"type": "string", "description": "Memory key (skip for list)", "nullable": True},        "value":  {"type": "string", "description": "Value to store (set only)",  "nullable": True},    }    output_type = "string"      def __init__(self, *args, **kwargs):        super().__init__(*args, **kwargs)        self._store: dict[str, str] = {}      def forward(self, action: str, key: str = None, value: str = None) -> str:        if action == "set":            self._store[key] = value            return f"Stored '{key}' = '{value}'"        elif action == "get":            return self._store.get(key, f"Key '{key}' not found.")        elif action == "list":            return "Keys: " + ", ".join(self._store.keys()) if self._store else "Memory empty."        return "Unknown action. Use: set | get | list"

class DuckDuckGoTool(Tool):      name        = "web_search"    description = "Performs a web search and returns top results as plain text."    inputs = {        "query":       {"type": "string",  "description": "The search query."},        "max_results": {"type": "integer", "description": "Results to return (1-10).", "nullable": True},    }    output_type = "string"      def forward(self, query: str, max_results: int = 3) -> str:        try:            from duckduckgo_search import DDGS            with DDGS() as ddgs:                results = [                    f"* {r['title']}n  {r['href']}n  {r['body'][:200]}"                    for r in ddgs.text(query, max_results=max_results)                ]            return "nn".join(results) if results else "No results found."        except Exception as e:            return f"Search failed: {e}"   @tool def factorial(n: int) -> str:    return f"{n}! = {math.factorial(n)}"   show("celsius_to_fahrenheit(100)", celsius_to_fahrenheit(100)) show("PrimeTool — 97",             PrimeTool().forward(97)) show("PrimeTool — 100",            PrimeTool().forward(100)) m = MemoTool() m.forward("set", "author", "Ada Lovelace") show("MemoTool get 'author'",      m.forward("get", "author"))   section("SECTION 3 · Managing Tools  (agent.tools dict)")   console.print(Panel(""" The Toolbox class was removed in v1.x. Tools live in  agent.tools, a plain Python dict keyed by tool name. """, title="[bold green]Tools Dict[/bold green]"))   section("SECTION 4 · LLM Engines")   console.print(Panel(""" SmolAgents supports multiple LLM backends via  LiteLLMModel. We use  gpt-4o-mini. """, title="[bold green]Engine Options[/bold green]"))   from smolagents import LiteLLMModel   MODEL_ID = "openai/gpt-4o-mini" engine   = LiteLLMModel(model_id=MODEL_ID, api_key=OPENAI_API_KEY) console.print(f"[green]Engine ready:[/green] {MODEL_ID}")

section("SECTION 5 · CodeAgent")   from smolagents import CodeAgent   code_agent = CodeAgent(    tools           = [celsius_to_fahrenheit, PrimeTool(), MemoTool(), DuckDuckGoTool()],    model           = engine,    max_steps       = 6,    verbosity_level = 1, )   console.print("n[bold]Initial agent.tools keys:[/bold]", list(code_agent.tools.keys())) code_agent.tools["factorial"] = factorial console.print("[dim]After adding factorial:[/dim]", list(code_agent.tools.keys()))   console.print("n[bold yellow]Task 1:[/bold yellow]") result1 = code_agent.run(    "Convert boiling point (100C) and body temperature (37C) to Fahrenheit. "    "Which is higher and by how much?" ) show("CodeAgent — Task 1", result1)   console.print("n[bold yellow]Task 2:[/bold yellow]") result2 = code_agent.run("What is 17 times 19? Is that result prime? Also check 7919.") show("CodeAgent — Task 2", result2)   console.print("n[bold yellow]Task 3:[/bold yellow]") result3 = code_agent.run("Compute 10! using the factorial tool.") show("CodeAgent — Task 3", result3)

section("SECTION 6 · ToolCallingAgent (ReAct)")   from smolagents import ToolCallingAgent   react_agent = ToolCallingAgent(    tools           = [celsius_to_fahrenheit, PrimeTool(), MemoTool()],    model           = engine,    max_steps       = 5,    verbosity_level = 1, )   console.print("n[bold yellow]Task 4:[/bold yellow]") result4 = react_agent.run(    "Then retrieve both facts and summarise them." ) show("ToolCallingAgent — Task 4", result4)   section("SECTION 7 · Multi-Agent Orchestration  (v1.8+ API)")   math_agent = CodeAgent(    tools           = [PrimeTool()],    model           = engine,    max_steps       = 4,    name            = "math_specialist",    description     = "Handles mathematical questions and primality checks.",    verbosity_level = 0, )   research_agent = ToolCallingAgent(    tools           = [DuckDuckGoTool(), MemoTool()],    model           = engine,    max_steps       = 4,    name            = "research_specialist",    description     = "Searches the web and stores or retrieves facts from memory.",    verbosity_level = 0, )   manager_agent = CodeAgent(    tools           = [],    model           = engine,    managed_agents  = [math_agent, research_agent],    max_steps       = 8,    verbosity_level = 1, )   console.print("n[bold yellow]Task 5:[/bold yellow]") result5 = manager_agent.run(    "Find out what year Python was first released (use research_specialist), "    "then check whether that year is a prime number (use math_specialist)." ) show("Manager Agent — Task 5", result5)
